Nickel Iron Chromium Austenitic Alloy Stainless Steel Tube 2.4858 Incoloy 825 UNS N08825

Incoloy 825 UNS N08825 Nickel iron chromium austenitic alloy Stainless Steel tube 2.4858

Material Description:

Incoloy 825 (UNS N08825) is a nickel-iron-chrome austenitic alloy with added molybdenum, copper, and titanium. Special corrosion resistance in oxidizing and reducing environments.

Chromium and molybdenum can resist chloride pitting and various oxidizing environments. Adding titanium makes the material more stable during welding and less susceptible to sensitization. This non-sensitization property makes the material resistant to intergranular corrosion even when exposed to the susceptibility temperature range.

Incoloy 825 (UNS N08825) has good corrosion resistance to various processing environments, including sulfuric acid, sulfurous acid, phosphoric acid, nitric acid, hydrofluoric acid, organic acids and alkalis such as sodium, potassium hydroxide, acid chloride, etc.

Description:
Incoloy 825 N08825 2.4858 Nickel iron chromium austenitic alloy Stainless Steel Pipe or Tube

Material: Incoloy 825 / N08825 / 2.4858 / NS142 / NC21FeDu / W.N r.2.4858 / NiCr21Mo / NA16 / NiFe30Cr21Mo3

Main chemical composition:

Ni: 38-46

Cr: 19.5-23.5

Fe: balance

C: ≤0.025

Mn: ≤1.0

Si: ≤0.5

Mo: 2.5-3.5

Cu: 1.5-3.0

Co: ≤1.0

Al: ≤0.2
Ti: 0.6-1.2

Size Range for tubing:

Process:
Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
Gas tungsten arc welding, Plasma arc welding (PAW),Submerged arc welding (SAW) For Welded Pipe or Tube

Finish: Annealed & pickled, bright annealing, polished

Ends: Beveled or plain end, square cut, burr free ,Plastic Cap at Both end

Packing: Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.

Inspection and Test Procedure
1. 100% PMI,Spectro Chemical Aanlysis Test for Raw Material
2. 100% Dimension & Visual Examination
3. Mechanical Properties Test Include Tension Test,Flaring Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test
4. 100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test (ET or UT)
5. Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor)
6. Straightness Test (optional)
7. Roughness Test (optional)
8. Intergranular Corrosion Test(optional)
9. Impact Test (optional)
10. Grain Size Determinations (optional)
NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION.
